Power Required	80-120 Hp
Working Width	100 in
Overall Width	106 in
Blade Ground Clearance (Four Gears)	0.2-0.9-1.7-2.4 in
Max. Cutting Diameter	Depends On The Type Of Grass
Offset Distance from The Center (Maximum)	130 in
Tilt-Up Angle	90°
Tilt-Down Angle	55°
Number Of Blades	24
Number of Belts	4
Blade Type	Hammer
Blade Weight	2.6 lbs
Blade Material	Cast Steel
Belt Adjustment	Bolt Tightening
Rotor Diameter	5.5 in
Rotor Thickness	0.5 in
Rear Roller Diameter	6 in
Rear Roller Thickness	0.25 in
PTO Shaft Speed	540 rpm
Deck Thickness	2 in
Side Plate Thickness	0.25 in
Gearbox (RPM 540)	65 HP CMR Italian gearbox
Driveline Shaft Length	06B-73SBWith Shear Bolt; 73in-126in
Spline End	1.375in  Z6
3-Point Hitch	CAT 2
Gearbox 0il Type	85W-90
Finish	Powder Coating
Warranty	1 Year
Shipping Box	121 X 43 X 37in
Weight (N.W./G.W.)	2100 /2344 lbs
